Model
|
Max.
Flow
GPM
|
Max.
Head
FT
|
Max.
Temp
°F
|
Max.
Visc
SSU
|
Max.
Spec
Grav.
|
Connections
|
x
Immersion
Depth
in
|
Wetted**
Materials
|
MOTOR DATA
|
Shp.
Wt.
Lbs
|
Overall
Dimensions
In.
|
|
Inlet
|
Outlet
|
HP
|
RPM
|
Volts
|
PH
|
Hz
|
Encl
|
|
TN-41-1/2-F
|
62
|
25
|
225
|
500
|
1.1
|
—
|
1" FPT
|
7
|
CI
|
1/2
|
1725
|
230/460
|
3
|
60/50
|
TEFC
|
60
|
19 x 9 x 11
|
|
TN43H-2-F
|
90
|
73
|
225
|
300
|
1.1
|
—
|
1 1/4" FPT
|
9 1/2
|
CI
|
2
|
3450
|
230/460
|
3
|
60/50
|
TEFC
|
90
|
24 x 9 x 11
|
|
TN53-3/4-E
|
100
|
30
|
225
|
500
|
1.1
|
—
|
1 1/8" FPT
|
9 1/2
|
CI
|
3/4
|
1725
|
115/230
|
1
|
60/50
|
TEFC
|
62
|
22 x 9 x 11
|
|
TN53-3/4-F
|
100
|
30
|
225
|
500
|
1.1
|
—
|
1 1 /4" FPT
|
9 1/2
|
CI
|
3/4
|
1725
|
230/460
|
3
|
60/50
|
TEFC
|
62
|
22 x 9 x 11
|
|
TN53H-3-F
|
100
|
90
|
225
|
300
|
1.1
|
—
|
1 1/2" FPT
|
9 1/2
|
CI
|
3
|
3450
|
230/460
|
3
|
60/50
|
TEFC
|
100
|
24 x 9 x 11
|
|
TN53HH-3-F
|
100
|
100
|
225
|
300
|
1.1
|
—
|
1 1/2" FPT
|
9 1/2
|
CI
|
3
|
3450
|
230/460
|
3
|
60/50
|
TEFC
|
100
|
24 x 9 x 11
|
|
TN63-1-E
|
140
|
26
|
225
|
300
|
1.1
|
—
|
1 1/2" FPT
|
10 1/8
|
CI
|
1
|
1725
|
115/230
|
1
|
60/50
|
TEFC
|
100
|
26 x 9 x 10
|
|
TN63-1-F
|
140
|
26
|
225
|
300
|
1.1
|
—
|
1 1/2" FPT
|
10 1/8
|
CI
|
1
|
1725
|
230/460
|
3
|
60/50
|
TEFC
|
100
|
26 x 9 x 10
|
|
TN73-1-1/2-F
|
180
|
27
|
225
|
300
|
1.1
|
—
|
2" FPT
|
10 1/8
|
CI
|
1 1/2
|
1725
|
230/460
|
3
|
60/50
|
TEFC
|
105
|
27 x 9 x 10
|
|
IMS08-E
|
10
|
20
|
225
|
500
|
1.1
|
1/2" FPT
|
1/2" FPT
|
N/A
|
CI, NR
|
1/8
|
3450
|
115/230
|
1
|
60
|
TEFC
|
17
|
6 x 6 x 7
|
|
IMSOE-F
|
10
|
20
|
225
|
500
|
1.1
|
1/2" FPT
|
1/2" FPT
|
N/A
|
CI, NR
|
1/8
|
3450
|
230/460
|
3
|
60/50
|
TEFC
|
17
|
6 x 6 x 7
|
|
IMS25-E
|
20
|
32
|
225
|
500
|
1.1
|
3/4" FPT
|
3/4" FPT
|
N/A
|
CI, NR
|
1/4
|
3450
|
115/230
|
1
|
60
|
TEFC
|
37
|
8 x 8 x 9
|
|
IMS25-F
|
20
|
32
|
225
|
500
|
1.1
|
3/4" FPT
|
3/4" FPT
|
N/A
|
CI, NR
|
1/4
|
3450
|
230/460
|
3
|
60/50
|
TEFC
|
37
|
8 x 8 x 9
|
|
IMS50-F
|
32
|
42
|
225
|
500
|
1.1
|
3/4" FPT
|
3/4" FPT
|
N/A
|
CI, AL
|
1/2
|
3450
|
230/460
|
3
|
60/50
|
TEFC
|
40
|
8 x 8 x 11
|
|
IMS75-F
|
43
|
51
|
225
|
500
|
1.1
|
1" FPT
|
1" FPT
|
N/A
|
CI, AL
|
3/4
|
3450
|
230/460
|
3
|
60/50
|
TEFC
|
51
|
8 x 8 x 12
|
|
IMS100-F
|
48
|
60
|
225
|
500
|
1.1
|
1" FPT
|
1" FPT
|
N/A
|
CI, AL
|
1
|
3450
|
230/460
|
3
|
60
|
TEFC
|
53
|
8 x 8 x 12
|
|
IMV08-E
|
10
|
20
|
225
|
500
|
1.1
|
—
|
3/8" FPT
|
5
|
CI, NR
|
1/4
|
3450
|
115/230
|
1
|
60
|
TEFC
|
15
|
12 x 5 x 5
|
|
IMV08-F
|
10
|
20
|
225
|
500
|
1.1
|
—
|
3/8" FPT
|
5
|
CI, NR
|
1/8
|
3450
|
230/460
|
3
|
60
|
TEFC
|
15
|
12 x 5 x 5
|
|
IMV25-E
|
20
|
32
|
225
|
500
|
1.1
|
—
|
1/2" F PT
|
6
|
CI, NR
|
1/4
|
3450
|
115/230
|
1
|
60
|
TEFC
|
31
|
15 x 7 x 7
|
|
IMV25-F
|
20
|
32
|
225
|
500
|
1.1
|
—
|
1/2" FPT
|
6
|
CI, NR
|
1/4
|
3450
|
230/460
|
3
|
60
|
TEFC
|
31
|
15 x 7 x 7
|
|
IMV50-F
|
35
|
43
|
225
|
500
|
1.1
|
—
|
3/4" FPT
|
8 1/4
|
CI, AL
|
1/2
|
3450
|
230/460
|
3
|
60
|
TEFC
|
41
|
18 x 8 x 8
|
|
IMV75-F
|
45
|
52
|
225
|
500
|
1.1
|
—
|
1" FPT
|
9 7/8
|
CI, AL
|
3/4
|
3450
|
230/460
|
3
|
60
|
TEFC
|
51
|
21 x 8 x 8
|
|
IMV100-F
|
50
|
60
|
225
|
500
|
1.1
|
—
|
1" FPT
|
9 7/8
|
CI, AL
|
1
|
3450
|
230/460
|
3
|
60
|
TEFC
|
51
|
21 x 8 x 8
|
|
Other seal configurations available for
temperatures up to 350°F.
* Contact a Water Cooling Engineer for assistance in selecting
pumps for fluids over 500 SSU.
** Also available in All Bronze and 316SSS construction.
See page 5 for material legend.
|
Contact a Water Cooling Application Engineer for assistance
in selecting pumps for fluids with specific gravity over 1.1.
Also available in TEFC and Explosion Proof.
|
|
